Ultrasonic Assisted Extraction

ultrasound-assisted extraction of phenolic compounds from jussara and blueberry fruits using the response surface methodology (RSM). ultrasound-assisted extraction was found to be more efficient to extract phenolic compounds from both fruits than the conventional extraction.

Send Inquiry

Product Details

Ultrasonic Assisted Extraction

The interaction of pressure waves (ultrasound) with a liquid medium leads to the formation of cavities in liquid. These cavities undergo continuous compression and rarefactions when they interact with positive and negative pressure cycles. This goes on until the cavities reach a critical radius, which is determined by the frequency of ultrasound. The implosion of bubbles created a local temperature of 5000K and pressures as high as 1000atm.

Ultrasonic Extraction Of Traditional Chinese Medicine And Natural Medicine:

Ultrasonic Assisted Extraction (UAE) is an advanced, green extraction technology that utilizes ultrasonic cavitation, high shear force and micro-turbulence to rapidly break plant cell walls. It effectively releases internal bioactive ingredients with lower temperature, shorter time, higher yield and less solvent consumption compared with traditional heating extraction and soaking methods. Widely applied in botanical extraction, nutraceutical, cosmetic, pharmaceutical and food processing industries, it supports laboratory R&D, pilot testing and full industrial scale-up production.

Ultrasonic Assisted Extraction is the ideal pre-extraction and fine-extraction solution for hemp raw materials. Controlled ultrasonic cavitation disrupts hemp plant cell structures, fully releasing CBD, CBG, CBN, terpenes and flavonoids from hemp biomass. It significantly improves cannabinoid extraction yield while protecting thermally sensitive active substances from high-temperature degradation. The process retains the full-spectrum efficacy of hemp extracts, perfectly matching the production requirements of CBD crude oil, refined oil and hemp-derived functional concentrates. It is widely used for standardized hemp raw material processing and high-purity cannabinoid preliminary extraction.

Ultrasonic Assisted Extraction Parameter

Model/Data	Sono-20-1000	Sono-20-2000	Sono-20-3000	Sono-15-3000
Frequency	20±0.5 KHz	20±0.5 KHz	20±0.5 KHz	15±0.5 KHz
Power	1000W	2000W	3000W	3000W
Voltage	110/220V
Temperature	300℃
Pressure	35 MPa
Intensity of sound	20 W/cm²	40 W/cm²	60 W/cm²	60 W/cm²
Max Capacity	10 L/Min	15 L/Min	20 L/Min	20 L/Min
Horn Material	Titanium

Ultrasonic Assisted Extraction Application

Traditional herbal extraction suffers from long soaking time, low dissolution rate and severe active ingredient loss. Ultrasonic extraction efficiently breaks plant cell walls to fully release flavonoids, polyphenols, alkaloids, saponins and glycosides from various herbs, roots, leaves and flowers. It operates at low temperature to preserve the biological activity of heat-sensitive components, improving extraction efficiency and product purity. Suitable for ginseng, chamomile, rosemary, green tea, honeysuckle and dozens of botanical raw materials, it provides high-quality extracts for health supplements and herbal formulations.

Functional food production requires high activity and high retention rate of nutritional ingredients. UAE technology efficiently extracts natural antioxidants, vitamins, carotenoids and polysaccharides from fruits, vegetables, grains and agricultural by-products. It maximizes the retention of active nutrients without destroying natural structures, improving the added value of raw materials. Widely used for extracting fruit polyphenols, plant proteins, dietary fiber and natural antioxidant components, it supports the production of functional concentrates, oral liquids and nutritional fortifiers, and complies with global clean-label and green-processing trends.

Core Technical & Application Advantages

Low-Temperature & Activity Protection: No high-temperature heating, fully protects heat-sensitive active ingredients such as cannabinoids and vitamins

Higher Extraction Yield: Cell wall disruption greatly increases the release rate of bioactive components

Time & Cost Saving: Shortens extraction cycle, reduces solvent dosage and production energy consumption

Full-Scale Compatibility: Covers lab R&D, pilot trial and industrial continuous production

Green & Clean Process: Physical extraction method with no chemical residue, compliant with food, cosmetic and pharmaceutical GMP standards

Patent Certificate

Certified by ISO 9001 & CE standards, this industrial-grade ultrasonic extraction system features 20-40kHz No adjustable frequency and 500W-3000W high-power output, achieving over 95% extraction efficiency while maintaining thermal stability (≤45°C) for sensitive compounds Equipped with titanium alloy corrosion-resistant probes and digital PID temperature control.Includes 24/7 global technical support and 3-year performance warranty.
