Electric Lifted Ultrasonic Homogenizer

Electric lifted Ultrasonic Homogenizer

Ultrasonic Homogenizer



The Electric Lifted Ultrasonic Homogenizer is a precision device that combines ultrasonic cavitation technology with an electric lifting system. Its core function is to homogenize, emulsify, disperse, and disrupt cells in liquid samples. It is widely applicable to sample pretreatment needs in fields such as biomedicine, food chemistry, and materials science.





Core Functions: Precisely Addressing Multi-Scenario Processing Needs

• Efficient Homogenous Dispersion

High-frequency ultrasound (typically 20kHz) creates a cavitation effect in liquids, forming tiny bubbles that burst instantly, releasing enormous energy. This rapidly disperses solid particles, nanomaterials, or immiscible liquids into a homogeneous system, achieving homogenized particle sizes down to the nanometer scale. Its processing efficiency is 3-5 times higher than traditional mechanical stirring.

• Electric Lift Adjustment

Equipped with a programmable electric lift mechanism, it supports 1mm precision height adjustment, automatically adapting to containers of varying volumes, eliminating manual adjustment errors and minimizing operator contact with samples, enhancing experimental safety.

• Intelligent Sample Protection

Equipped with power feedback control and temperature monitoring, it detects sample temperature changes in real time, preventing localized overheating that can damage heat-sensitive samples. Overload protection also protects the device from damage due to excessive load.

• Data Logging

Working parameters and temperatures are recorded, and data export is available for convenient experimental documentation and research comparison.

Typical Applications
Medical Extraction: Chinese herbal medicine extraction, beverage processing
Food Industry: Homogenization of dairy products (to improve taste), dispersion of plant-based protein beverages (to prevent stratification);
Material Science: Dispersion and preparation of nanoparticles (such as graphene and quantum dots), emulsification and polymerization of polymer materials;
Environmental Monitoring: Eutrophication Treatment, Ultrasonic Algaecide, Ultrasonic Sterilization
Core Technical Parameters (Mainstream Models)
Ultrasonic Frequency: 20kHz;
Output Power: 1000-3000W;
Lifting Stroke: 50-300mm (electrically driven, remote control available);
Compatible Containers: 2-10L (standard with probes of varying specifications);
Control: Touchscreen operation, supports timing (0-999 minutes), power memory, and data export.
