Flow Cell Ultrasonic Homogenizer
An ultrasonic homogenizer flow cell is a device that uses high frequency sound waves to break down particles and cells in a liquid sample. It consists of a flow cell chamber where the sample is passed through and an ultrasonic transducer that emits high frequency sound waves into the sample.
Product Details
Flow cell ultrasonic homogenizer
Description
An ultrasonic homogenizer flow cell is a device that uses high frequency sound waves to break down particles and cells in a liquid sample. It consists of a flow cell chamber where the sample is passed through and an ultrasonic transducer that emits high frequency sound waves into the sample. The sound waves cause the cells and particles to break apart, resulting in a homogenized sample. This technology is commonly used in scientific research, medical testing, and industrial processing applications.
Parameter
|
Model/Data |
Sono-20-1000 |
Sono-20-2000 |
Sono-20-3000 |
Sono-15-3000 |
|
Frequency |
20±0.5 KHz |
20±0.5 KHz |
20±0.5 KHz |
15±0.5 KHz |
|
Power |
1000W |
2000W |
3000W |
3000W |
|
Voltage |
110/220V |
|||
|
Temperature |
300℃ |
|||
|
Pressure |
35 MPa |
|||
|
Intensity of sound |
20 W/cm² |
40 W/cm² |
60 W/cm² |
60 W/cm² |
|
Max Capacity |
10 L/Min |
15 L/Min |
20 L/Min |
20 L/Min |
|
Horn Material |
Titanium |
|||
Application of sonochemistry
Flow cell ultrasonic homogenizers are a type of equipment widely used in industries such as food, pharmaceutical, and biotechnology. The ultrasonic energy generated by these homogenizers can be used for various applications, including:
1. Cell disruption: Flow cell ultrasonic homogenizers are used to break down cells and release intracellular materials. This process is critical in the extraction of proteins, enzymes, and DNA from living organisms.
2. Emulsification: Homogenizers can be used to break down or disperse immiscible liquids, such as oil and water, to create stable emulsions. This process is used in the food industry for the production of mayonnaise, cream, and other products.
3. Particle size reduction: Homogenizers can be used to reduce the particle size of solids suspended in liquids, such as producing nano-size particles of drugs and other substances.
4. Degassing: The ultrasonic energy generated by homogenizers can be used to remove bubbles and gas from liquids, which is important in the production of carbonated beverages and some pharmaceutical formulations.
5. Mixing: Homogenizers can be used for mixing and blending liquids, which is valuable in the production of chemicals and other specialty products.
Overall, flow cell ultrasonic homogenizers offer a powerful and versatile tool for a wide range of applications in various industries, providing high-quality results with minimal sample damage and processing time.
